TRUCK-MOUNTED AERIAL PLATFORM

are range from 10 meters to 42 meters, which are ideal for all kinds of businesses. For instance, lamp post construction, building external wall cleaning, repair/installation of a canal, decorate an advertisement board and many more. They can also provide lighting and wide angle performance, excellent for commercial and movie filming.

TRUCK-MOUNTED AERIAL PLATFORM

42M CTE
42M CTE

42M CTE
42M CTE

42M CTE
42M CTE

42M CTE
42M CTE

1/4

 42M CTE

WORKING HEIGHT: 42meters
MAKE/MODEL: CTE
CAPACITY: 200kg/ 2 persons
BASKET SIZE(LxWxH): 1.5x1x1.1m

TRUCK WEIGHT: 30ton

TRUCK SIZE(LxWxH): 10.9x2.5x3.95m



FEATURE: The highest articulating truck-mounted aerial platform, Up-side down V level lift movement, rotatable basket. Ideal for external walls repair, glass curtain wall cleansing, etc.

32M CTE
32M CTE

32M CTE
32M CTE

32M CTE
32M CTE

32M CTE
32M CTE

1/5

 32M CTE

WORKING HEIGHT: 32meters
MAKE/MODEL: CTE
CAPACITY: 250kg/ 2 persons

BASKET SIZE(LxWxH): 2.4x0.8x1.1m

TRUCK WEIGHT: 16ton

TRUCK SIZE(LxWxH): 9.75x2.3x4.11m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

32_VL3892 Tadano 32M (5)
32_VL3892 Tadano 32M (5)

32_VL3892 Tadano 32M (37)
32_VL3892 Tadano 32M (37)

TADANO AT-300CG
TADANO AT-300CG

32_VL3892 Tadano 32M (5)
32_VL3892 Tadano 32M (5)

1/4

 32M TADANO(2)

WORKING HEIGHT: 32meters
MAKE/MODEL: TADANO | AT-300CG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.5x0.7x0.95m

TRUCK WEIGHT: 14ton

TRUCK SIZE(LxWxH): 9.43x2.3x3.7m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

29.3M Italmec
29.3M Italmec

1/2

 29.3M ITAMEC

 (2)

WORKING HEIGHT: 29.3meters
MAKE/MODEL: ITALMEC. ITALY
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 0.7x2.2x1.13m

TRUCK WEIGHT: 16ton

TRUCK SIZE(LxWxH): 9.32x2.49x3.9m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

29M CTE
29M CTE

29M CTE
29M CTE

1/1

 29M CTE

WORKING HEIGHT: 29meters
MAKE/MODEL: CTE | ZED 29J
CAPACITY: 230kg/ 2 persons

BASKET SIZE(LxWxH): 1.8x0.7x1.1m

TRUCK WEIGHT: 16ton

TRUCK SIZE(LxWxH): 10.28x2.47x3.5m

FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

29M Aichi
29M Aichi

29M Aichi
29M Aichi

29M Aichi
29M Aichi

1/2

 29M AICHI

WORKING HEIGHT: 29meters
MAKE/MODEL: AICHI
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.37x0.81x0.95m

TRUCK WEIGHT: 14ton

TRUCK SIZE(LxWxH): 8.86x2.44x4.04m

FEATURE: Telescopic. Ideal for external walls repair and glass curtain wall cleansing. Oscillating working platform.

27m TADANO AT-255CG
27m TADANO AT-255CG

27m TADANO AT-255CG
27m TADANO AT-255CG

27m TADANO AT-255CG
27m TADANO AT-255CG

27m TADANO AT-255CG
27m TADANO AT-255CG

1/3

 27.5 TADANO (3)

WORKING HEIGHT: 27.5meters
MAKE/MODEL: TADANO | AT-255CG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.2x0.7x0.95m

TRUCK WEIGHT: 10ton

TRUCK SIZE(LxWxH): 8.05x2.19x3.7m

FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc.

1/2

 25 SOCAGE

工作高度: 25米
品牌|型號:  SOCAGE | 250.00
最高載重: 200公斤/ 2人

工作台(長x闊x高): 1.83x0.8x0.99米

車輛重量: 10噸

車輛尺寸(長x闊x高):  7.78x2.29x3.2米

特點: Z臂,適合外牆維修和玻璃幕牆清潔,隧道內安裝工程等。工作台可左右擺動。

22M TADANO AT-200S
22M TADANO AT-200S

22M TADANO AT-200S
22M TADANO AT-200S

22M TADANO AT-200S
22M TADANO AT-200S

22M TADANO AT-200S
22M TADANO AT-200S

1/3

 22M TADANO

 (Super Deck)

WORKING HEIGHT: 22meters
MAKE/MODEL: TADANO | AT-200S
CAPACITY: 1000kg/ 2 persons

BASKET SIZE(LxWxH): 4.6x1.94x1.01m

TRUCK WEIGHT: 9ton

TRUCK SIZE(LxWxH): 7.44x2.26x3.81m


FEATURE: Extra large working platform. Ideal for external walls repair, glass curtain wall cleansing, and tunnel maintenance, etc. 360-degree continuous rotation basket.

21M Socage
21M Socage

21M Socage
21M Socage

21M Socage
21M Socage

21M Socage
21M Socage

1/3

 21 SOCAGE

WORKING HEIGHT: 21meters
MAKE/MODEL: SOCAGE
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.83x0.8x0.99m

TRUCK WEIGHT: 10ton

TRUCK SIZE(LxWxH): 7.78x2.29x3.2m


FEATURE: Articulating. Ideal for external walls repair, glass curtain wall cleansing, and tunnel maintenance, etc. Oscillating working platform.

21.5M Tadano AT-195CG
21.5M Tadano AT-195CG

21.5M Tadano AT-195CG
21.5M Tadano AT-195CG

1/1

 21.5M TADANO

 (2)

WORKING HEIGHT: 21.5meters
MAKE/MODEL: TADANO | AT-195CG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.2x0.7x0.95m

TRUCK WEIGHT: 10ton

TRUCK SIZE(LxWxH): 7.94x2.2x3.4m

FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc.

18M Tadano AT157CG
18M Tadano AT157CG

18M Tadano AT157CG
18M Tadano AT157CG

18M Tadano AT157CG
18M Tadano AT157CG

1/2

 18M TADANO

WORKING HEIGHT: 18meters

MAKE/MODEL: TADANO | AT-157CG

CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.2x0.7x0.95m

TRUCK WEIGHT: 9ton

TRUCK SIZE(LxWxH): 5.6x2.11x3.725m



FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

17.5M Tadano AT-155CG
17.5M Tadano AT-155CG

17.5M Tadano AT-155CG
17.5M Tadano AT-155CG

中環郵政局 17.5M Tadano AT-155CG
中環郵政局 17.5M Tadano AT-155CG

17.5M Tadano AT-155CG
17.5M Tadano AT-155CG

1/3

 18M TADANO

 (2)

WORKING HEIGHT: 18meters
MAKE/MODEL: TADANO | AT-155CG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.63x0.9x0.95m

TRUCK WEIGHT: 7.5ton

TRUCK SIZE(LxWxH): 6.15x2x3.2m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

16M Tadano
16M Tadano

銅鑼灣真光中學
銅鑼灣真光中學

16M Tadano
16M Tadano

1/2

 16M TADANO

WORKING HEIGHT: 16meters
MAKE/MODEL: TADANO | AT-155TG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.07x0.71x0.91m

TRUCK WEIGHT: 5.5ton

TRUCK SIZE(LxWxH): 5.8x2.18x3.66m


FEATURE: Articulating jib allows working platform freely reaches over obstructions. Ideal for tree cutting and external walls cleansing, etc. Oscillating working platform.

14_FX8808 Tadano 14M (8)
14_FX8808 Tadano 14M (8)

14M Tadano AT-120TG
14M Tadano AT-120TG

14M Tadano AT-120TG
14M Tadano AT-120TG

14_FX8808 Tadano 14M (8)
14_FX8808 Tadano 14M (8)

1/4

 14M TADANO

WORKING HEIGHT: 14meters
MAKE/MODEL: TADANO | AT-120TG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 1.12x0.77x0.94m

TRUCK WEIGHT: 9ton

TRUCK SIZE(LxWxH): 5.61x2.13x3.45m

FEATURE: Telescopic. Ideal for external walls repair, glass curtain wall cleansing and tunnel maintenance, etc. Oscillating working platform.

14M Tadano AT-120S
14M Tadano AT-120S

14M Tadano AT-120S
14M Tadano AT-120S

14M Tadano AT-120S
14M Tadano AT-120S

14M Tadano AT-120S
14M Tadano AT-120S

1/3

 14M TADANO (2)

 (Super Deck)

WORKING HEIGHT: 14meters
MAKE/MODEL: TADANO | AT-120S
CAPACITY: 1000kg/ 2 persons

BASKET SIZE(LxWxH): 2.5x1.55x1.02m

TRUCK WEIGHT: 9ton

TRUCK SIZE(LxWxH): 5.92x2.1x3.7m

FEATURE: Extra large working platform. Ideal for external walls repair, glass curtain wall cleansing and tunnel maintenance, etc. 360 degree continuous rotation basket.

14_VT8535  (19)
14_VT8535 (19)

14_VT8535  (19)
14_VT8535 (19)

1/4

 14M TADANO

WORKING HEIGHT: 14meters
MAKE/MODEL: TADANO | AT-120TG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 0.7x1x0.95m

TRUCK WEIGHT: 7.5ton

TRUCK SIZE(LxWxH): 5.42x2.13x2.85m


FEATURE: Tiny vehicle body, telescopic, oscillating working platform. Ideal for external walls repair, glass curtain wall cleansing, etc.

12M  TADANO AT-100TG
12M TADANO AT-100TG

12M  TADANO AT-100TG
12M TADANO AT-100TG

12M  TADANO AT-100TG
12M TADANO AT-100TG

12M  TADANO AT-100TG
12M TADANO AT-100TG

1/3

 12M TADANO

WORKING HEIGHT: 12meters
MAKE/MODEL: TADANO | AT-100TG
CAPACITY: 200kg/ 2 persons

BASKET SIZE(LxWxH): 0.7x1x0.9m

TRUCK WEIGHT: 5.3ton

TRUCK SIZE(LxWxH): 4.91x1.9x2.9m


FEATURE: Tiny vehicle body, telescopic, oscillating working platform. Ideal for external walls repair, glass curtain wall cleansing, etc.
